Ozone in the Wine Industry

Typical applications for ozone in the wine industry include the following:

- Barrel washing
- Surface and equipment sanitization
- Tank cleaning
- Clean-in-place (CIP) of process and transfer piping

Typically, 2.5 ppm ozone concentration for 2 minutes on healthy barrels after a hot water flush is sufficient. If the barrel is severely contaminated, a
5-minute treatment may be required. Ozone enhances the barrels by preventing organic buildup that undercuts the longevity of these precious vessels. Ozone washing of wine barrels saves wineries considerable money on the high costs of replacing contaminated wine barrels. As a result, most ozone installations yield a very high return on investment and short break even period.


Surface & Equipment Sanitation
A broad range of surfaces and equipment are routinely sanitized with ozonated water to control unwanted microbes and cross contamination. Harvest bins, crushing and destemming machines, conveyors, even floors are routinely and effectively sanitized using ozone. Bottles and bottling equipment are sanitized with ozone as well.


Tank Cleaning
While ozone is still the non-chlorinated cleaner of choice for initial sanitation, experience has proven that it should also be used for additional follow-on
rinses as well. Stainless steel tanks may stand empty for a week or more after initial sanitization. Many wineries rinse all stainless steel vessels with ozonated water immediately prior to filling to ensure proper sanitization.


CIP of Piping
The highest risk of contamination in the in winemaking process comes from transferring the wine between the many necessary tank and barrel treatment steps. To mitigate this risk, wineries adopt stringent measures to their CIP processes.

CIP involves cleaning and sanitizing of pump systems, pipes, tanks, hoses, filters, bottling lines, etc. Using soaps, detergents, pressurized water and chemicals like chlorine or
iodaphore solutions, these cleaning steps can require multiple rinses, often with hot water or steam, to remove residues. This labor and energy intensive process is also a worker safety concern and can consume up to ten gallons of water for each gallon of wine produced.

Ozone, already an integral part of CIP sanitization in the food processing industry, is a natural choice for wine’s process machines. Using ozone in their CIP process saves time as well as costs.


Typical Winery Ozone Systems
Smaller wineries often utilize mobile ozone contacting systems that provide all of the critical components of ozone contacting in a convenient cart-based system. Such systems permit ozone-injected water to be applied wherever needed in the winery operations. Larger wineries often opt for centralized
facility-wide ozone contacting systems. These stationary, integrated ozone systems pipe ozone injected water throughout the facility to specific points of use – including automated barrel washing equipment and centralized CIP systems.
